5HZ~500KHz Ultrasonic Pulse Velocity Tester Non Destructive Tester High Performance

Hebei Better United Import And Export Co., Ltd.

5HZ~500KHz Ultrasonic Pulse Velocity Tester Non Destructive Tester High Performance

  • 1
  • 2

Brand Name : Btutest

Model Number : BTU-UPVT

Certification : SGS, INTERTEK

Place of Origin : Made in China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 80000 sets per month

Delivery Time : 5-8 work days

Packaging Details : Concrete Testing Equipment Standard export wooden box

Name : Ultrasonic Pulse Velocity Tester

Warranty : 1 Year

Standard : EN 12504 PART. 4 BS 1881:203 ASTM C597 NF P18-418 UNE 83308 UNI 7997 UNI 9189 UNI 9524

Ultrasonic indication error : ±0.1μs

Ultrasonic transducer operating frequency : 50KHz

Instrument ultrasonic frequency range : 5HZ~500KHz

Contact Now

Ultrasonic Pulse Velocity Tester, High Performance Concrete Testing Equipment

Standard:

EN 12504 PART. 4 BS 1881:203 ASTM C597 NF P18-418 UNE 83308 UNI 7997 UNI 9189 UNI 9524

Features:

※ newly upgraded wireless cloud transmission function (optional);

※ it integrates six functions of pile, strength, defect, width, depth and pavement bending resistance;

※ with stable performance and powerful functions, it is the choice of users with diversified needs in engineering testing, teaching and scientific research;

※ newly upgraded wireless cloud transmission function (optional);

※ adopt three proof shell design, waterproof, dustproof and shockproof;

※ multi function: two methods can be used to test the compressive strength of concrete: rebound method and ultrasonic rebound method. It can measure the rebound value, sound time and sound speed, which is simple and convenient;

※ high quality: using imported sensors and advanced ARM processor, the test is fast and accurate, and the test results can be analyzed on site;

※ easy to use: full Chinese interface with prompt, quick learning and on-site test;

※ powerful: the instrument can store 4000 groups of data and record the test date, which is convenient for users to view and manage. The USB interface can quickly import the data to the upper computer for analysis and processing.

※ the Chinese and English interfaces can be switched freely, making it more convenient for foreign customers to use.

Description:

Comprehensive instrument for testing concrete strength. It can be used not only as a common rebound tester, but also as an ultrasonic rebound comprehensive method tester, which can measure the rebound value, sound time and sound speed. It is suitable for nondestructive testing of compressive strength of ordinary concrete in various construction projects.Concrete Testing Equipment

Specification:

Host parameter Waterproof level:IP65 Screen size: 5 inches Volume: 195x140x45mm Weight: 0.85kg
Ultrasonic indication error ±0.1μs
Ultrasonic transducer operating frequency 50KHz
Instrument ultrasonic frequency range 5HZ~500KHz
Data transmission mode Wireless cloud transmission(optional)
Springback apparatus nominal kinetic energy 2.207J
Stiffness of Spring Strike 785.0±40.0(N/m)
Impact length of ram 75.0±0.3mm
Rebound value average steel anvil rate 80±2
Rebound value indication error ≤±0.5
Powder supply mode Large capacity lithium battery. powder supply time is more than 8 hours
Working environment -10~40℃

5HZ~500KHz Ultrasonic Pulse Velocity Tester Non Destructive Tester High Performance

5HZ~500KHz Ultrasonic Pulse Velocity Tester Non Destructive Tester High Performance

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.

Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
