ASTM D6760-02 Non Destructive Testing Equipment Cross Hole Ultrasonic Monitor

Hebei Better United Import And Export Co., Ltd.

ASTM D6760-02 Non Destructive Testing Equipment Cross Hole Ultrasonic Monitor

  • 1
  • 2
  • 3

Brand Name : Btutest

Model Number : BTU930

Certification : SGS, INTERTEK

Place of Origin : Made in China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 80000 sets per month

Delivery Time : 5-8 work days

Packaging Details : Concrete Testing Equipment Standard export wooden box

Name : Cross Hole Ultrasonic System TWO Channels Automatic

Warranty : 1 Year

Standard : ASTM D6760-02

Master control unit : Buit-in A8 industrial control motherboard

Display : 10.1 inch, high brightness, TFT color LCD capacitive screen

Operational mode : Touch screen

Contact Now

Cross Hole Ultrasonic System Two Channels Automatic Concrete Testing Equipment

Standard:

ASTM D6760-02

Features:

※ newly upgraded wireless cloud transmission function (optional);

※ it integrates six functions of pile, strength, defect, width, depth and pavement bending resistance;

※ with stable performance and high cost performance, it is the choice of users with diversified needs in teaching and scientific research;

※ semi reflective and semi transparent, high brightness, TFT color LCD screen;

※ full touch screen operation, simple and convenient, stable and reliable;

※ large memory capacity, working time can reach more than 10 hours;

※ it can send and receive two signals, automatically collect and automatically record the height and sound time waveform to improve the work efficiency;

※ the original measuring point waveform can be played back, overwritten and deleted at will;

※ it can be connected to the digital rebound meter probe for ultrasonic rebound comprehensive strength measurement;

※ the memory capacity is large, and the U disk is used to transfer data and support software upgrading through the U disk;

※ the special analysis software has powerful functions, and data analysis and processing, report generation, and printing of reports can be easily completed;

※ the Chinese and English interfaces can be switched freely, making it more convenient for foreign customers to use.

Description:

Rapid and continuous detection of foundation piles by ultrasonic transmission method; Rapid detection of continuous wall integrity; Structural concrete compressive strength test; Detection of crack depth of structural concrete; Detection of crack width of structural concrete; Bending resistance test of concrete pavement; Mechanical property testing of non-metallic materials such as rock mass and concrete.Concrete Testing Equipment

Specification:

Product Model BTU930
Master control unit Buit-in A8 industrial control motherboard
Display 10.1 inch, high brightness, TFT color LCD capacitive screen
Operational mode Touch screen
Storage mode Built-in Electronic Hard Disk(>8GB)+Large Capacity U Disk
Data transmission mode Wireless Cloud Transport(Options)
Acquisition mode Single and double channel automatic continuous and acquisition
Number of dispossable profiles Tow
Channel number 1 emission+2 reception
Trigger mode Signal triggering
Sampling period(mus) 0.05~409.6 Multistage Options
Acoustic time accuracy(us) 0.05
Acoustic time range(mus) +1677700
Width measurement function Measuring range: 0~10mmMeasurement accuracy: 0.01mm
Dynamic range(dB) 0.5
Emission voltage(V) Sixty-five, 250, 500 and 1000 gears adjustable
Communication interface UBS, Bluetooth, Wifi
Working hours(h) More than 8
Power supply mode Built-in lithium batteryExternal 220V~ 16V AC/CD
Working environment Temperature(℃) -10℃~ + 40℃Humidity(RH) <90%
Host size(mm) 300*200*55

ASTM D6760-02 Non Destructive Testing Equipment Cross Hole Ultrasonic Monitor

ASTM D6760-02 Non Destructive Testing Equipment Cross Hole Ultrasonic Monitor

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.

Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
